The whole machine is adopted international famous brand appliances and computer software,the quality is stable and reliable .Man-machine interface, Multi-point touch screen control ,computer order management, easy to operate.Replace the order faster(can be stored 999 orders in advance)There is lack of ink alarm device and the real-time monitoring for the ink working condition system .
Optional: ceramic anilox roller, doctor blade and set ink system, stacking machine.
The Machine technique parameter:
width of machine inside | 2200mm | 2600mm | 2800mm |
max.paper size | 900*2000mm | 1200*2400mm | 1400*2600mm |
max.printing size | 900*1800mm | 1200*2200mm | 1400*2400mm |
skip feeding paper | 1100*2000mm | 1400*2400mm | 1600*2600mm |
min paper size positive knife negative knife | 300*640mm 300*720mm | 350*720mm 350*740mm | 400*720mm 400*740mm |
design speed(piece/min) | 200 | 180 | 150 |
economic speed(piece/min) | 80-180 | 80-160 | 80-130 |
min.slotting distance positive knife negative knife | 150*150*150*150mm 250*90*250*90mm | 170*170*170*170mm 260*90*269*90mm | 170*170*170*170mm 260*90*269*90mm |
max.die-cutting size | 900*1900mm | 1200*2300mm | 1400*2500mm |
